Vehicle Comments
This 2005 Victory Hammer with 3,924 miles is price at just $6,995.
Engine and transmission | |
---|---|
Displacement: | 1638.8 ccm (100.00 cubic inches) |
Engine type: | V2, four-stroke |
Compression: | 9.8:1 |
Bore x stroke: | 101.0 x 102.0 mm (4.0 x 4.0 inches) |
Valves per cylinder: | 4 |
Fuel system: | Injection. Electronic Fuel Injection with 44mm throttle bodies |
Fuel control: | Single Overhead Cams (SOHC) |
Cooling system: | Oil & air |
Gearbox: | 6-speed |
Transmission type, final drive: | Belt |
Clutch: | Wet, multi-plate |
Exhaust system: | Large bore slash-cut dual exhaust with common volume |
Chassis, suspension, brakes and wheels | |
Rake (fork angle): | 33.1° |
Front suspension: | Inverted cartridge telescopic fork, 43mm fork tube, 5.1in |
Front wheel travel: | 130 mm (5.1 inches) |
Rear suspension: | Single, mono-tube gas, Forged and Cast Aluminum with rising rate linkage swing-arm. Preload adjustable spring |
Rear wheel travel: | 100 mm (3.9 inches) |
Front tyre: | 130/70-R18 |
Rear tyre: | 250/40-R18 |
Front brakes: | Single disc. Floating rotor with 4-piston caliper |
Diameter: | 300 mm (11.8 inches) |
Rear brakes: | Single disc. Floating rotor with 2-piston caliper |
Diameter: | 300 mm (11.8 inches) |
Physical measures and capacities | |
Dry weight: | 298.0 kg (657.0 pounds) |
Overall height: | 671 mm (26.4 inches) |
Ground clearance: | 147 mm (5.8 inches) |
Wheelbase: | 1669 mm (65.7 inches) |
Fuel capacity: | 17.03 litres (4.50 gallons) |
